The KPI Resource uses many custom components to create the dashboards. The following sections list these components by function. Click on the component image to navigate to the component page for more information.

Single Tag Components​

These components visualize one tag in a view.

Value Unit Label

Value Unit Label 		Sparkline

Sparkline 		Notepad

Notepad

Single Tag Boundary-aware Components​

These components display the value and show where it lies within the spec limits that are configured in EngLow and EngHigh of the tag.

Daily Production

Daily Production 		Moving Analog Indicator

Moving Analog Indicator
Progress Bar

Progress Bar 		Simple Gauge

Simple Gauge

Multiple Tag Components​

These components visualize more than one tag in a view.

Bar Chart

Bar Chart 		Line Chart

Line Chart
Line KPI

Line KPI Screenshot 		Progress KPI

Progress KPI

Popups​

These components are designed to be used as popup views to show historical trends.

Popup

Popup 		Popup Dual Tag

Popup Dual Tag
